Clip for fastening the barbed wire rings – Russian Federation patent №91903
Russian Patent: №91903
Author: Tkachenko Yuriy Vladimirovich
Section of the IPC: B21F 25/00 – Barbed wire, mesh, fencing, wire fabrics
Use: in the manufacture of protective safety barriers for sensitive sites barbed wire Egoza. The inventive clip has a metal form; the form is made of flat tape. The ends of the form are in the form of whiskers. One end of the form has a central mustache with the parties to expand in the direction of the form. The second end of the form has two extreme whiskers gap between them an adequate shape and size to the central whiskers at the opposite end of the form. By bending the clip into a ring, whiskers tightly mated each other and are arranged in one plane. Technical advantages: increased barrier properties due to the increased rigidity of fencing clips and the impossibility of its extension as a result of the forced change of its structure more rigid.
The invention relates to hardware production, and more specifically, to the production of barbed tape that is used as a safety barrier and are designed to prevent unauthorized penetration of sensitive sites and can be used in the manufacture of protective barbed-cutting ribbons.
Known clip which has a form of metal wire of circular section, the ends of which in the original state smoothly (radially) are bent in the same direction at almost right angles. Clips placed in the special tool with which it folds into the ring [see the Prospect of the German company «Haubold». Clip GDH galvanized wire with a diameter of 1.8 mm value of 45 euros per pack (10 thousand units)].
This very clip is closest in nature and effect is achieved, and therefore taken as a prototype.
The main drawback of the known clip is that it is made of a thin metal wire, which limits its functional properties. This disadvantage is explained as follows. The known clip is made from relatively thin wire – 1.8 mm so that it was easy to bend in the ring. But such a thin wire has a low rigidity, so easy to clip unbent, virtually hands. Consequently, when load on the fence, it can spontaneously unbend. In addition, it is easy to straighten force: it is enough to catch anything, such as a screwdriver, for the end of the form, bend the ends of the clip and remove it from the enclosure. In addition, it is possible without significant effort bite, even ordinary household scissors. All this reduces the reliability of the safety barrier, built using known clips from low their functional properties, in particular rigidity.
The basis of the utility model the task of enhancing the functional properties of the clip by changing its structure by providing the form at the ends of his mustache that no gaps are matched to each other in a bent (operational) state clip.
This object is achieved in that the clip having a metal form, the ends of which in the original state smoothly (radially) are bent in one direction substantially at right angles, as proposed, the form is made of a flat tape and the ends of the form are in the form of whiskers, and one end of the form has a central mustache with the parties to expand in the direction of the form and the second end of the form has two extreme mustache, the gap between them adequate in size and shape to the central whisker at the opposite end of the form, and, when bent clip in the ring, mustache tight are mated with each other and are arranged in one plane.
Implementation of clips of thin metal strip eliminates the possibility of her snacking that household scissors that metal shears as a bent into the ring clip scissors impossible to push (ring covered and clamped elements of barbed tape barriers, i.e. there is no space where one could push the scissors) and the ends of the ring are thin enough to allow for them to seize scissors. Perform all the clips in the form of whiskers allows, after bending the clip into the ring to form a tight locking connection without any gaps between the sides of the whiskers, and in the same plane, which precludes extension ends, because of the absence of gaps, there is no place to insert, for example, screwdriver or a knife blade. A tape bent into a ring, has sufficient rigidity and is not spontaneously flexes under load on the guardrail.
Further essence of the utility model will be explained in conjunction with illustrative pictures, showing:
- Figure 1 – scan proposed clips, a plan view;
- Figure 2 – Clip proposed in the initial state, a plan view;
- Figure 3 – proposed in a bent clip (operating, operational) state, a plan view.
Asking clip contains the form of 1 of the metal strip. At one end of the form 1 is located a central whisker 2 with lateral sides extending in a direction of the form 1. The second end of the form 1 is two extreme whiskers 3, the gap between which corresponds in shape and size to the central whisker 2 at the opposite end of the form 1. When bending the clip into a ring, whisker 2 enters the gap between the antennae 3 and tightly mated with them, i.e. without gaps, and all the whiskers 2 and 3 are located in the same plane without a gap between their sides. Consequently, bent in a ring clip is a cylinder with no protrusions on its envelope surface that is transformed in a sufficiently rigid structure that is difficult to forcibly straightened, as for the ends of the cylinder cannot capture anything for the reason that the cylinder is made of a thin metal strip, and it is impossible to bend the whiskers, as they do not protrude beyond the surface of the cylinder and are in contact with each other without gaps.
The technical advantages of the proposed technical solution, compared with the prior art, include improving the barrier properties due to increased rigidity fences clips and the impossibility of its extension force due to the change of its construction more rigid.
Social benefits from the use of technical proposals are in comparison with the prototype, obtained by improving the reliability of protection by fencing sensitive sites.
Useful model formula
The clip having a metal form, the ends of which in the original state smoothly (radially) are bent in one direction substantially at right angles, characterized in that the form is made of a flat tape and the ends of the form are in the form of whiskers, and one end of the form has a central whisker with sides extending in a direction towards the form and a second end of the form has two extreme whisker gap between which is adequate to the shape and size of the central whisker at the opposite end of the form, and when bending the clip into a ring whiskers tightly mated each other and are arranged in one platitude.
